Professional security and AI.
IndoorCam combines the convenience of Wi-Fi cameras with advanced security features. The fallback communication channel with an Ajax hub ensures that the facility is never out of sight, even if Wi-Fi fails. Equipped with a PIR sensor and built-in AI, the device accurately detects movement and recognises people, animals and vehicles. Users can always get a clear view of indoor activity in excellent quality thanks to the IndoorCam's wide-angle HDR camera.

Live view, instant call
Stay connected to your property and control it anywhere, day or night. With HD video streaming and two-way audio, you can instantly see, hear and react to any situation with your smartphone. From scaring off unwanted visitors to monitoring your space, IndoorCam combines professional surveillance with easy-to-use functionality.

Extended Wi-Fi range for no delays and crashes
Forget home security cameras that disconnect from the Wi-Fi network at the worst possible time. IndoorCam is designed to be less sensitive to radio interference and maintain a stable connection up to 500 metres in line-of-sight - five times further than competing solutions. This extended range offers more installation flexibility, as installers no longer need to place the Wi-Fi router directly at the camera. For users, it ensures seamless communication and uninterrupted streaming when needed.

Reliable connection via Wi-Fi
Connecting IndoorCam to an Ajax hub provides a reliable backup communication channel. If the Wi-Fi connection is lost, the camera continues to send events, alarms and photos using Ajax's secure Jeweller and Wings radio protocols. With a communication range of up to 1,700 metres with a hub and robust Ajax anti-sabotage measures, IndoorCam remains an active part of the intrusion protection system, keeping users informed and in control.

Specifications:

Videostream:
- Camera with 4 MP CMOS sensor:
- Solution up to 2560 × 1440 px.
Camera viewing angles:
- Horizontaal: 110°.
- Vertical: 60°.
Videoprotocol:
- JetSparrow (fast and encrypted peer-to-peer video protocol developed by Ajax Systems):
Opslagopties:
- Ajax Cloud:
- NVR (Network Video Recorder).
Videocodec:
- H.264>
Dynamisch bereik:
- HDR for improved accuracy of details in light and dark scenes.
Communicatiekanaal:
- Wi-Fi (802.11 b/g/n):
- 2.4 GHz, up to 2 Mbit/s for the 2K video channel.
Communication technologies from Jeweller and Wings:
- Wireless communication technologies for commands, alarms, events and photo verifications:
- Backup communication channel when the device is added to the hub.
Belangrijkste kenmerken:
- Two-way communication for clear and loud speech.
- Motion detection via built-in PIR sensor and software-based image frame analysis.
- Object detection with AI for people, pets and vehicles.
- Smart IR illumination up to 8 m with automatic intensity adjustment.
- Visual verification of Ajax alarms via selected cameras.
Microfoon:
- For two-way communication and audio recording:
Audio codec and audio processing:
- G722 audio codec:
- Always active noise reduction and echo cancellation.
LED-indicatie:
- Indicates the current status of the device:
PIR-detectie:
- Sensitive elements: 1 × PIR sensor:
- Motion detection distance: up to 4 m (depending on sensitivity settings).
- Motion detection angle: Horizontal: 110°; Vertical: 60°.
- Sensitivity: 3 levels, adjustable by PRO users or users with administrator rights.
Installatie-aanbevelingen:
- Only for indoor use:
- Do not install in direct sunlight to prevent overheating.
Sabotagebescherming:
- Mounting screw for fastening:
- mTLS encrypted connection for data protection.
- Authentication via Ajax Cloud (without local access rights).
- Safe automatic firmware update via OTA signature verification.
- Privacy through distribution of user access rights in mobile apps and PRO Desktop.
Detection of communication loss:
- Wi-Fi: adjustable from 30 s.
- Jewelry/Wings: after 36 s.
Stroomvoorziening:
- Power supply: 12 V⎓ ± 20%, 1 A.
- Current consumption of device:To be determined.
Behuizing:
- Dimensions: 128 × 74 × 76 mm
- Weight: 235 grams.
- Operating temperature: from 0 °C to +40 °C.
- Operating humidity: up to 90 per cent without condensation.
- Protection class: IP20.
Kleuren:
- Black (RAL 9005) and White (RAL 9003).
