DS-2AE4225TI-D Turbo HD PTZ, 2MP, 25x zoom, IR 100mtr

Important!Make sure your current recorder can handle the HD resolution of this camera.This is not an IP camera.Hikvision DS-2AE4225TI-D Turbo... Read more

Delivery time 1 - 2 working days

€549,00€453,72 Incl. VATExcl. VAT

    • Pay afterwards within 30 days - both private and business

      <p>Pay afterwards within 30 days - both private and business</p>
    • Showroom in Gorinchem
    • The best service and warranty
    • 3500+ customers give us a 4.71 / 5
    • Free remote installation
    • Free returns within 14 days
    Product Description

    Important!

    Make sure your current recorder can handle the HD resolution of this camera.
    This is not an IP camera.

    Hikvision DS-2AE4225TI-D Turbo HD PTZ, 2MP, 25x zoom, IR 100mtr

    This Hikvision PTZ can capture high-quality video in low-light environments and features a 2MP lens.
    The built-in CMOS chip enables WDR and real-time 1920 x 1080 resolution. Using the 25× optical zoom lens and IR cut filter, the camera offers more detail over an expansive area. Thanks to the built-in WDR of 120dB, the camera can deal with all types of backlight.
    The black anti-reflective glass increases the luminosity that helps achieve IR distance of up to 100m.

    This 2MP PTZ works using HD-TVI technology but can also be converted to a regular uncompressed CVBS signal via a switch.

    Specificaties:

    • 1/2.8'' Progressive Scan CMOS

    - 1920×1080

    - 25X Optical Zoom

    - WDR 120dB

    - Up to 100m IR distance

    - 3D intelligent positioning function

    - Switchable Turbo HD and CVBS outputs

    Technische Specificaties:

    Camera
    Image Sensor: 1/2.8" Progressive Scan CMOS
    Effective Pixels: 1920(H)x1080(V)
    Signal System: PAL/NTSC
    Minimum Illumination: Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR
    White Balance: Auto / Manual / ATW / Indoor / Outdoor
    AGC: Auto/Manual
    BLC: ON/OFF
    WDR: Support
    Shutter Time: 1-1/10,000s
    Day& Night: ICR
    Digital Zoom: 16X
    Privacy Masking: 8 privacy masks programmable
    Auto Focus: Auto / Semi-automatic / Manual
    Lens
    Focal Length: 4-92.0mm, 23x
    Zoom Speed: Approx.3s(Optical Wide~Tele)
    Angle of View: 49-2.2 degree(Wide-Tele)
    Minimum Working Distance: 10~1,000mm(Wide~Tele)
    Aperture Range: F1.4-F3.5
    Pan & Tilt
    Pan Range: 360°endless
    Pan Speed: Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s
    Tilt Range: -15°-90° (Auto Flip )
    Tilt Speed: Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
    Proportional Zoom: Rotation speed can be adjusted automatically according to zoom multiples
    Number of Preset: 256
    Patrol: 8 patrols, up to 32 presets per patrol
    Pattern: 4 patterns, with the total recording time not less than 10 minutes
    Power loss recovery: Support
    Park Action: Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
    PTZ Position Display: ON/OFF
    Freeze Frame: Support
    Infrared
    IR irradiation distance: 100m
    IR irradiation angle: Adjustable by zoom
    General
    RS-485 Protocols: HIKVISION, Pelco-P, Pelco-D, self-adaptive
    Menu Language: English
    Power Supply: 12V DC
    Power Consumption: Max.18W
    Working Temperature/Humidity: -30 °C-65°C(-22°F-149°F)
    90% or less
    Protection Level: IP66 standard (outdoor dome)
    TVS 4,000V lightning protection, surge protection and voltage transient protection
    Mounting: Various mounting modes optional
    Dimensions: Φ164.5(mm)×295(mm)
    Weight (approx.): 2Kg (4.41Ibs)
    Mount Option: Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner;
    Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ
